Factory Direct Supply CBHC-2063 63 cc/rev Hydraulic Gear Pump

ปริมาตรกระจัด:63 ซีซี/รอบ

แรงดันที่กำหนด:แรงดัน 20 MPa (2900 psi)

แรงดันสูงสุด:แรงดัน 25 MPa (3625 psi)

ความเร็วสูงสุด:ความเร็ว 2500 รอบต่อนาที

ทิศทางการหมุน:สองทิศทาง

แบรนด์:BXHS

ประเภทสินค้า:ปั๊มเฟืองไฮดรอลิก

ซีรี่ส์ผลิตภัณฑ์:ซีรีส์ CBHC ปั๊มเฟืองไฮดรอลิก

ขนาดบรรจุภัณฑ์:34*18*18

น้ำหนักรวม:15.00 kg

สถานะสินค้า: มีสินค้าในสต็อก

189 ผู้เข้าชมที่กำลังมองหาผลิตภัณฑ์นี้

Factory Direct Supply CBHC-2063 63 cc/rev Hydraulic Gear Pump

Factory Direct Supply CBHC-2063 63 cc/rev Hydraulic Gear Pump

Factory Direct Supply CBHC-2063 63 cc/rev Hydraulic Gear Pump drawing image

Source the CBHC-2063 63 cc/rev Hydraulic Gear Pump directly from a Professional Manufacturer with 25+ years of expertise. Rated at 20 MPa (2900 psi) and 2200 r/min, this bidirectional pump is ideal for forklifts, loaders, and agricultural machinery. Backed by IATF 16949 certification and 100% factory testing, we offer reliable OEM/ODM solutions for global distributors.

ซีรีส์ CBHC ปั๊มเฟืองไฮดรอลิก พารามิเตอร์
ปริมาตรกระจัด 32 ซีซี/รอบ, 40 ซีซี/รอบ, 50 ซีซี/รอบ, 63 ซีซี/รอบ, 80 ซีซี/รอบ, 100 ซีซี/รอบ, 25 ซีซี/รอบ, 110 ซีซี/รอบ
แรงดันที่กำหนด แรงดัน 20 MPa (2900 psi), แรงดัน 22 MPa (3190 psi)
แรงดันสูงสุด แรงดัน 25 MPa (3625 psi), 28 เมกะปาสคาล (4061 ปอนด์ต่อตารางนิ้ว)
ความเร็วที่กำหนด ความเร็ว 2200 รอบต่อนาที
ความเร็วสูงสุด ความเร็ว 2500 รอบต่อนาที
ทิศทางการหมุน Left (counter-clockwise), Right (clockwise), สองทิศทาง
วัสดุ เหล็กหล่อ
โครงสร้าง ปั๊มเกียร์ภายนอก
เวอร์ชันหน้าแปลน หน้าแปลน SAE
ประเภทเพลา Rectangle Spline

**1. Factory Direct Supply of Hydraulic Gear Pump**
- Sourced directly from our 68,000㎡ manufacturing base with an annual capacity of 1,500,000 units, ensuring stable supply for Wholesale Direct Sales.
- Enjoy competitive pricing without middlemen, as we are a verified China Wholesale Factory committed to cost-effective B2B partnerships.

**2. Robust CBHC Series Gear Pump Specifications**
- Delivers a displacement of 63 cc/rev with a rated pressure of 20 MPa (2900 psi) and max pressure of 25 MPa (3625 psi) for heavy-duty tasks.
- Operates efficiently at a rated speed of 2200 r/min (max 2500 r/min) with bidirectional rotation, suitable for diverse hydraulic systems.

**3. Versatile 63cc Hydraulic Pump Applications**
- Engineered for material handling and construction equipment, including forklifts, telehandlers, skid steer loaders, and mini-excavators.
- Perfectly compatible with international major brands, serving as a reliable replacement part for industrial vehicles and agricultural tractors.

**4. Precision Quality Control & Certification**
- Every unit undergoes 100% bench testing for pressure, flow, and sealing, supported by 260+ vertical machining centers and CMM inspection.
- Certified under IATF 16949 and CE standards, with SGS verification and 25+ patents, guaranteeing Exported Worldwide quality consistency.

**5. Custom OEM/ODM Available Services**
- Supported by 35+ senior engineers with 10+ years of experience, we provide tailored solutions including logo laser marking and private label packaging.
- Offers secure anti-rust treatment and heavy-duty wooden crate packaging, making us a preferred partner for Wholesale Hot Sale distributors.
