Global Distributors and Wholesalers Wanted for CBHC-2063 63 cc/rev Hydraulic Gear Pump

ปริมาตรกระจัด:63 ซีซี/รอบ

แรงดันที่กำหนด:แรงดัน 20 MPa (2900 psi)

แรงดันสูงสุด:แรงดัน 25 MPa (3625 psi)

ความเร็วสูงสุด:ความเร็ว 2500 รอบต่อนาที

ทิศทางการหมุน:สองทิศทาง

แบรนด์:BXHS

ประเภทสินค้า:ปั๊มเฟืองไฮดรอลิก

ซีรี่ส์ผลิตภัณฑ์:ซีรีส์ CBHC ปั๊มเฟืองไฮดรอลิก

ขนาดบรรจุภัณฑ์:34*18*18

น้ำหนักรวม:15.00 kg

สถานะสินค้า: มีสินค้าในสต็อก

235 ผู้เข้าชมที่กำลังมองหาผลิตภัณฑ์นี้

Global Distributors and Wholesalers Wanted for CBHC-2063 63 cc/rev Hydraulic Gear Pump

Global Distributors and Wholesalers Wanted for CBHC-2063 63 cc/rev Hydraulic Gear Pump

Global Distributors and Wholesalers Wanted for CBHC-2063 63 cc/rev Hydraulic Gear Pump drawing image

This CBHC-2063 Hydraulic Gear Pump features 63 cc/rev displacement, 20 MPa rated pressure, and bidirectional rotation, ideal for forklifts and loaders. Backed by a Professional Manufacturer with 25+ years of experience and IATF 16949 certification, it ensures reliable performance for heavy-duty applications.

ซีรีส์ CBHC ปั๊มเฟืองไฮดรอลิก พารามิเตอร์
ปริมาตรกระจัด 32 ซีซี/รอบ, 40 ซีซี/รอบ, 50 ซีซี/รอบ, 63 ซีซี/รอบ, 80 ซีซี/รอบ, 100 ซีซี/รอบ, 25 ซีซี/รอบ, 110 ซีซี/รอบ
แรงดันที่กำหนด แรงดัน 20 MPa (2900 psi), แรงดัน 22 MPa (3190 psi)
แรงดันสูงสุด แรงดัน 25 MPa (3625 psi), 28 เมกะปาสคาล (4061 ปอนด์ต่อตารางนิ้ว)
ความเร็วที่กำหนด ความเร็ว 2200 รอบต่อนาที
ความเร็วสูงสุด ความเร็ว 2500 รอบต่อนาที
ทิศทางการหมุน Left (counter-clockwise), Right (clockwise), สองทิศทาง
วัสดุ เหล็กหล่อ
โครงสร้าง ปั๊มเกียร์ภายนอก
เวอร์ชันหน้าแปลน หน้าแปลน SAE
ประเภทเพลา Rectangle Spline

**1. High-Efficiency Hydraulic Gear Pump Specifications**
- Delivers consistent flow with 63 cc/rev displacement, operating at rated pressure of 20 MPa (2900 psi) and max pressure of 25 MPa.
- Supports bidirectional rotation with max speed up to 2500 r/min, ensuring versatile integration into complex hydraulic systems.

**2. Versatile CBHC Series Gear Pump Applications**
- Engineered for Material Handling and Construction sectors, perfectly compatible with Forklifts, Telehandlers, Skid Steer Loaders, and Mini-Excavators.
- Designed as a direct replacement for international brands, offering seamless fitment for Wheel Loaders and Backhoe Loaders without system modification.

**3. Reliable 63cc Hydraulic Pump Quality Control**
- Manufactured in our 68,000㎡ facility with 260+ CNC machines, every unit undergoes 100% bench testing for pressure, flow, and sealing integrity.
- Certified under IATF 16949 and CE standards, with SGS detection and 25+ patents guaranteeing zero-defect delivery for critical industrial vehicles.

**4. Customizable OEM Hydraulic Gear Pump Solutions**
- Supported by 35+ senior engineers, we offer full OEM/ODM services including custom castings, logo laser marking, and private label packaging.
- Flexible customization allows distributors to create unique product lines while maintaining the high durability expected from a Wholesale China Factory.

**5. Factory Direct Sales & Global Logistics**
- Benefit from Factory Direct Sales pricing with an annual capacity of 1,500,000 units, ensuring stable supply for large-scale wholesale orders.
- Products are secured with anti-rust treatment and heavy-duty wooden crates, supporting Exported Worldwide logistics with fast lead times for urgent projects.
