Log Splitter Hydraulic Valve | P81 Model | Factory Direct & Customizable

วิธีการควบคุม:ด้วยตนเอง

สปูล:1 สปูล

อัตราการไหลที่กำหนด:80 ลิตร/นาที (21.2 แกลลอนสหรัฐ/นาที)

แรงดันสูงสุด:แรงดันสูงสุด 19 เมกะปาสคาล

พอร์ตทางเข้า:ขนาด G1/2

พอร์ตทางออก:ขนาด G3/4

ขนาดพอร์ต:ขนาด G3/4

แบรนด์:BXHS

ประเภทสินค้า:วาล์วเครื่องผ่าฟืน

ซีรี่ส์ผลิตภัณฑ์:ซีรีส์ P81 วาล์วเครื่องผ่าฟืน

ขนาดบรรจุภัณฑ์:27*16*12

น้ำหนักรวม:4.80 kg

สถานะสินค้า: มีสินค้าในสต็อก

2159 ผู้เข้าชมที่กำลังมองหาผลิตภัณฑ์นี้

Log Splitter Hydraulic Valve | P81 Model | Factory Direct & Customizable

Log Splitter Hydraulic Valve | P81 Model | Factory Direct & Customizable

Log Splitter Hydraulic Valve | P81 Model | Factory Direct & Customizable drawing image

The P81 hydraulic valve is a high-performance, heavy-duty valve designed for use in tractor-powered log splitters. It features a manual control method, 1 section monoblock construction, 80 L/min flow rate, and 250 bar maximum pressure. This durable valve is perfect for industrial applications and offers customizable options to meet your specific needs.

ซีรีส์ P81 วาล์วเครื่องผ่าฟืน พารามิเตอร์
วิธีการควบคุม ด้วยตนเอง
สปูล 1 สปูล
ช่วงอุณหภูมิโดยรอบ -40°C ถึง +80°C (-40°F ถึง +176°F)
ประเภทโครงสร้าง วาล์วแบบโมโนบล็อก
ส่วน 1 ส่วน
ช่วงความหนืดในการทำงาน 15 - 75 มม²/วินาที (15 cSt ถึง 75 cSt)
อัตราการไหลที่กำหนด 80 ลิตร/นาที (21.2 แกลลอนสหรัฐ/นาที), 95 ลิตร/นาที (25.1 แกลลอนสหรัฐ/นาที)
แรงดันสูงสุด แรงดันสูงสุด 19 เมกะปาสคาล
พอร์ตทางเข้า ขนาด G1/2
พอร์ตทางออก ขนาด G1/2
ขนาดพอร์ต ขนาด G3/4

The P81 model is a robust tractor joy stick log splitter hydraulic valve, ideal for industrial vehicles. This monoblock valve boasts a 1 section design and offers a rated flow of 80 L/min (21.2 US gpm) with a maximum pressure of 250 bar (3600 psi). It operates within a wide viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and can withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). The valve features a single spool with a kick-out setting pressure of 70~140bar (1015-2030psi). We offer this valve for manufacturing, OEM, private label, and custom orders, allowing you to tailor it to your specific requirements. We are also actively seeking distributors, wholesalers, agents, and traders worldwide. Contact us today to discuss your needs and explore the possibilities of this high-quality, customizable hydraulic valve.
